General
|
|
| Make | Mercedes-Benz |
| Model | 2004 CLK DTM AMG |
| Powertrain Layout | Front Engine / RWD |
| Base Price | Not Available |
|
Dimensions
|
| WheelBase |
2722 mm / 107.2 in |
| Length |
4650 mm / 183.1 in |
| Height |
1360 mm / 53.5 in |
| Width |
1800 mm / 70.9 in |
| Weight |
1748 kg / 3854 lbs |
| Front / Rear Track |
F 1569 mm / 61.8 in
R 1580 mm / 62.2 in
|
|
Engine
|
| Configuration |
AMG 5.4L Supercharged V8 |
| Valvetrain |
SOHC, 3 valves / cylinder |
| Displacement |
5439 cc / 331.9 cu in |
| Power |
434.0 kW / 582.0 bhp at 6100 rpm |
| Torque |
800.0 Nm / 590.0 ft lbs at 3500 rpm |
| Bore |
97 mm / 3.82 in |
| Stroke |
92 mm / 3.62 in |
| Compression Ratio |
10.5:1 |
| BHP / Liter |
107.0 bhp |
| Redline |
7000 rpm |
|
Transmission
|
| Type | 5-Speed Auto w/ Sequential Shift |
| Final Drive | 3.06:1 |
| 1st Gear Ratio | 3.59:1 |
| 2nd Gear Ratio | 2.19:1 |
| 3rd Gear Ratio | 1.41:1 |
| 4th Gear Ratio | 1.00:1 |
| 5th Gear Ratio | 0.831:1 |
| 6th Gear Ratio | Not Available |
|
Chassis & Body
|
| Steering | Rack & Pinion w/ Speed Sensitive Power Assist |
| Tire Sizes | F 255/35R-19
R 285/30R-20 |
| Brake Types | Carbon Vented Discs |
| Brake Size | F 360 mm / 14.2 in
R 330 mm / 13.0 in |
| Available ABS | Yes |
| Body Material | Aluminum w/ Steel Alloys |
|
Performance
|
| Top Speed | 320.0 kph / 198.8 mph |
| 0 - 30 mph | Not Available |
| 0 - 60 mph | 3.9 seconds |
| 0 - 100 mph | Not Available |
| 0 - ¼ mile | Not Available |
| Lateral Acceleration | Not Available |
| EPA City / Hwy | Not Available |
