General
|
|
| Make |
Ford |
| Model |
1999 Mustang FR500 Concept |
| Powertrain Layout |
Front Engine / RWD |
| Base Price |
$54 000 est. |
|
Dimensions
|
| WheelBase |
2700 mm / 106.3 in |
| Length |
4661 mm / 183.5 in |
| Height |
1326 mm / 52.2 in |
| Width |
1857 mm / 73.1 in |
| Weight |
1631 kg / 3587 lbs |
| Front / Rear Track |
F 1549 mm / 61.0 in
R 1544 mm / 60.8 in |
|
Engine
|
| Configuration |
V8 |
| Valvetrain |
DOHC, 4 valves / cylinder |
| Displacement |
4997 cc / 305.0 cu in |
| Power |
309.6 kw / 415.0 bhp @ 6800 rpm |
| Torque |
494.8 Nm / 365.0 ft lbs @ 4200 rpm |
| Bore |
94.0 mm / 3.70 in |
| Stroke |
90.0 mm / 3.54 in |
| Compression Ratio |
9.9:1 |
| BHP / Liter |
Not Available |
| Redline |
Not Available |
|
Transmission
|
| Type |
6-Speed Manual |
| Final Drive |
4.10:1 |
| 1st Gear Ratio |
Not Available |
| 2nd Gear Ratio |
Not Available |
| 3rd Gear Ratio |
Not Available |
| 4th Gear Ratio |
Not Available |
| 5th Gear Ratio |
Not Available |
| 6th Gear Ratio |
Not Available |
|
Chassis & Body
|
| Steering |
Rack & Pinion w/ Power Assist |
| Tire Sizes |
F 265/35ZR-18
R 295/35ZR-18 |
| Brake Types |
Vented & Cross-Drilled Discs |
| Brake Size |
F 356 mm / 14.0 in
R 330 mm / 13.0 in |
| Available ABS |
Yes |
| Body Material |
Not Available |
|
Performance
|
| Top Speed |
168.0 mph / 270.5 kph
(electronically limited) |
| 0 - 30 mph |
1.9 seconds |
| 0 - 60 mph |
4.5 seconds |
| 0 - 100 mph |
10.9 seconds |
| 0 - ¼ mile |
13.0 seconds |
| Lateral Acceleration |
0.94g |
| EPA City / Hwy |
16 / 23 mpg |
